Specifications

Specification

Generic Type (Primary)	Compact
Engine	3TNV80F-ZXKLST
Cylinder Liners	3
Engine Type	IDI
Engine Manufacturer	YANMAR
Emissions	Tier 4
Engine Power	Gross: 24.7 hp
Rated Engine Speed	2,800 RPM
Displacement	77.3 cu in

Fuel System

Fuel Type

Diesel

PTO

PTO Power, Rated Engine Speed	19.3 hp| Rear: 540 RPM
PTO Type	Independent
Drivetrain	No. of Speeds: 3 Ranges
Transmission	HST
Steering	Hydrostatic Power Steering

Brakes

Brake System Type

Wet, Multi Disc

Wheels & Tires

Tires, Front Specification	Ag: 23 x 8.5 – 12 | Versa Turf: 12 x 16.5
Tires, Rear Specification	Ag: 12 – 16.5 | Versa Turf: 12 x 16.5

Electric

Alternator

12-40 Amps

Hydraulics

Hydraulic Pump	Implement: 5.6 gpm | Implement: 5.6 gpm | Steering: 3.7 gpm
Hydraulic Flow	Total: 9.3 gpmHydraulic Flow Total: 9.3 gpm
Hydraulic Type	Remote Valves: 2 Pairs
Hitch/Type	Category, 3 pt hitch: CAT 1

Dimensions

Overall Length	rame to link: 111.9in
Wheelbase	63.4 in
Overall Width	Min. with Ag tires: 48.7 in
Height	to top of ROPS with Ag tires: 86.4 in

Capacities

Fuel Capacity	tank: 6.79 gal
Hitch Lift Capacity	1,896 lb

Weights

Weight

Total without ballast:1,764 lbs

Features

Lift Mechanism	Control System: Position
Lift Capacity	1067
Drive	4WD

Certain features may require an additional add-on package that may not be included in the retail or sale price. Please contact the dealership for full details.
