Specifications

Specification

Generic Type (Primary)	Compact
Engine	MHI
Engine Power	Gross: 24.6 hp
Rated Engine Speed	2,500 RPM
Cylinder Liners	3
Displacement	80.4 cu in
Cooling	Liquid-cooled

Fuel System

Fuel Type

Diesel

PTO

PTO Power, Rated Engine Speed	17.1 hp| Rear: 540 RPM
PTO Type	Independent
Drivetrain	No. of Speeds: 3 Ranges
Transmission	HST
Steering	Hydrostatic Power Steering

Brakes

Brake System Type

Wet, Multi-disc

Wheels & Tires

Tires, Front Specification	Ag: 7 – 14 | IND: 27X8.50-15 | VT: 27X8.50-15 | Turf: 25X8.50-14
Tires, Rear Specification	Ag: 11.2 – 24 | IND: 43X16.00-20 | VT: 43X16.00-20 | Turf: 41X14.00-20

Electric

Alternator

12V – 50 Amps

Hydraulics

Hydraulic Type	Control System: Position
Hydraulic Pump	Implement: 7.1 gpm | Steering: 4.6 gpm
Hydraulic Flow	Total: 11.7 gpm
Hitch/Type	Category, 3 pt hitch: CAT I

Dimensions

Overall Length	Frame to link: 119 in
Overall Width	With tires: 66 in
Wheelbase	66 in
Height	To top: 95 in

Capacities

Fuel Capacity	Tank: 10.6 gal
Hitch Lift Capacity	1,808 lb

Weights

Weight	Total without ballast: 3,007 bs
Lift Capacity	1965
Drive	4WD

Certain features may require an additional add-on package that may not be included in the retail or sale price. Please contact the dealership for full details.
