Specifications

Specification

Generic Type (Primary)	Compact
Engine	3TNV76F
Cylinder Liners	3
Cooling	Water-cooled
Emissions	Tier 4
Engine Power	Gross: 21.5 hp
Rated Engine Speed	3,000 RPM
Displacement	68.0 cu in

Fuel System

Fuel Injection

Indirect-injection

PTO

PTO Power, Rated Engine Speed	15.0 hp | Mid PTO: Standard (2500 rpm) | Rear PTO: Standard (540 rpm)
PTO Type	Independent
Drivetrain	No. of Speeds: 2 Ranges
Transmission	Hydrostatic Drive
Steering	Hydrostatic Power Steering

Brakes

Brake System Type

Wet, Multi-disc

Wheels & Tires

Tires, Front Specification	Industrial: 18×18.5 – 10/26 x 12.0 – 12 | Versa Turf: 18×18.5 – 10/26 x 12.0 – 12 | Ag: 7 – 14 / 11.2 – 24 | IND: 27X8.50-15 / 43X16.00-20 | VT: 27X8.50-15 / 43X16.00-20
Tires, Rear Specification	Industrial: 18×18.5 – 10/26 x 12.0 – 12 | Versa Turf: 18×18.5 – 10/26 x 12.0 – 12 | Ag: 7 – 14 / 11.2 – 24 | IND: 27X8.50-15 / 43X16.00-20 | VT: 27X8.50-15 / 43X16.00-20

Electric

Alternator

12V – 40 Amps

Hydraulics

Hydraulic Pump	Implement: 4.6 gpm | Steering: 2.1 gpm
Hydraulic Flow	Total: 6.7 gpm
Hitch/Type	Category, 3 pt hitch: CAT I

Dimensions

Overall Length	97 in (Frame to Link)
Overall Width	47 in with tires
Wheelbase	56 in
Height	to top of ROPS: 87 in

Capacities

Fuel Capacity	Tank: 6.6 gal
Hitch Lift Capacity	970 lb (728 @ 24”) (Hitch end)

Weights

Weight

Total without ballast: 1,433 lbs

Features

Lift Mechanism	Control System: Position
Lift capacity	966
Drive	4WD

Certain features may require an additional add-on package that may not be included in the retail or sale price. Please contact the dealership for full details.
